Product Brief
——
FOT3223 VFL Power Meteris an ideal tester used in quickly mechanical splicing and FTTx networks, and single optical connector port design greatly minimizes the operation, user doesn’t need to change the port between the OPM and VFL function when testing.
Specifications
Model | FOT3223 VFL&OMP |
Operating wavelength(Power Meter Module) | 850.980,1300,1310,1490,1550,1625,1650nm |
Detector Type | InGaAs |
Out put power(VFL module) | 1mW |
Power Measurement Range (dBm) | -60~+3 |
Uncertainty (dB) | ±0.5 |
Resolution | 0.01 |
Operation temperature (℃) | -10~+60 |
Storage Temperature (℃) | -25~+70 |
Auto-off function | Yes, Auto-off after 10 minutes idle time |
Battery Life @ OPM | 180 hours |
Battery Life @ VFL | 60 hours |
Power Supply | 3pcs AA Batteries |
Weight (without batteries) | 320g |
Size | 192*102*50 |
Key Features
Power meter and VFL integrated in one unit, optical light source optional
Wavelength identification automatically
Test result save up to 1000pc
Optical Port: FC, SC, ST interchangeable supports various optical connectors.
